SIM7500 Buy UHF RFID Module Online | SILION TECH

The coin size UHF RFID module SIM7500 is based on a next-generation Impinj E710 RAIN RFID reader chip, designed for low-cost RFID handheld devices and mobile readers. The SIM7500 module's low power consumption shapes only coin size, it's good for mobile devices.

Product Parameters

  • Hardware and OS

    • API Support C, C#/.NET, Java
  • Physical Characteristics

    • Dimensions 28mm L x 28mm W x 3.5mm H
    • Weight 5.8g
  • RFID Characteristics

    • Air Protocols EPC Class 1 Gen 2 (ISO 18000-6C)
    • Chipset Impinj E710
    • Frequency USA: 902-928MHz FCC (NA, SA)
      EU: 865-868MHz (ETSI)
      CN: 920-925MHz (CMIIT)
    • Programing Functions Tag RSSI Support
    • RF Output Power 5dBm-30dBm (±1dBm) adjustable
  • Performance

    • Reading Distance ≥3m, with 2dBi ceramic antenna
    • Anti-collision ≥900 tags/s
  • Connectivity

    • Communications 32 pin surface mount module (SMT compatible)
    • General Purpose I/O 2 Inputs (DC 0~3.3V),  2 Outputs (DC 0~3.3V)
  • Antenna

    • Antenna Ports Single mono-static RF port
  • Power

    • Power Supply 3.6V~5.0V +/-5%
  • Environmental

    • Operating Temp -26°C to +65°C
    • Storage Temp. -40°C - +85°C
    • Humidity 5-95% non-condensing (+25°C)

Product Description

The coin size UHF RFID module SLR7500 is based on a next-generation Impinj E710/E310 RAIN RFID reader chip, designed for low-cost RFID handheld devices and mobile readers. The SLR7500 module's low power consumption shapes only coin size, it's good for mobile devices.
