Based on Impinj E310 reader chip, the micro-size UHF RFID module SIM3800 has external dimensions of only 16.3 mm × 16.3 mm. Its Surface Mounted Devices (SMD) form factor allows for rapid and seamless integration; the maximum RF output power is 27 dBm. It is suitable for PDA and desktop RFID devices.

Product Description

● Based on the New Generation Impinj E310 reader chip.

● Supports Impinj Gen2X.

● Supports EPC global Gen2 (ISO 18000-6C).

● 27dBm RF power output.

● Surface Mounted Devices (SMD) form factor allows for rapid and seamless integration.

● Micro-size and low power consumption.

Technical Specifications

Hardware and OS
- Firmware Upgrade Support
- API Support C, C#/.NET, Java

Physical Characteristics
- Dimensions 16.3mm x 16.3mm x 2.6mm
- Weight 1.8g

RFID Characteristics
- Air Protocols EPC Class 1 Gen 2 (ISO 18000-6C)
- Chipset IMPINJ E310
- Frequency USA: 902-928MHz FCC (NA, SA)
  EU: 865-868MHz (ETSI)
  CN: 920-925MHz (CMIIT)
- RF Output Power 5dBm-27dBm (±1dB) adjustable
- Work Mode Fixed / hop frequency optional
- Sensitivity -73dBm

Connectivity
- Communications 20 pin surface mount module (SMT compatible)
- General Purpose I/O 2 Inputs (DC 0~3.3V), 2 Outputs (DC 0~3.3V)

Antenna
- Antenna Ports Single mono-static RF port

Performance
- Anti-collision >300 tags/s
- Reading Distance ≥3m with 2.5dBi antenna

Power
- Power Supply Input Voltage: DC 3.6 ~ 5.25V
  Power consumption in RF output mode: 3W (Peak Value), 0.6A@5V
  Power consumption in standby: 0.66W, 0.132A@5V

Environmental
- Operating Temp. -25°C to +65°
- Storage Temp. -40°C to +85°C
- Humidity 5-95% non-condensing (+25°C)
