SIM7200 | E710 | Buy UHF RFID Module Online

Impinj E710 RAIN RFID reader chip is a high-performance RFID card reader chip, aimed at IoT applications, with excellent read/write performance, high security and flexible configuration, and can provide communication interfaces directly connected to cloud platforms. Its high performance and reliability have been recognized and widely used in the industry. By incorporating the Impinj E710 chip into the design of SIM7200 module, it can further enhance the RFID device's card-reading and communication performance, providing users with more comprehensive and professional wireless communication solutions.

Product Description SIM7200

*With an absolute maximum of +30 dBm. Maximum power may have to be reduced to meet regulatory limits, which specify the combined effect of the module, antenna, cable, and enclosure shielding of the integrated product.

Recommended Products

SIM7100 | E710 | Buy UHF RFID Module Online | SILION TECH

The UHF high-performance module SIM7100 is based on the next-generation Impinj E710 RAIN RFID reader chip, designed for high-performance RFID handheld devices and mobile readers. The SIM7100 module provides an MMCX antenna interface that supports RF output up to 33 dBm. The module's high sensitivity, small size, good RF performance, and advanced anti-jamming design make it a preferred choice for mobile devices.

SIM7500 | E710 | Buy UHF RFID Module Online | SILION TECH

The coin size UHF RFID module SIM7500 is based on a next-generation Impinj E710 RAIN RFID reader chip, designed for low-cost RFID handheld devices and mobile readers. The SIM7500 module's low power consumption shapes only coin size, it's good for mobile devices.

SIM7400 | E710 | Buy UHF RFID Module Online | SILION TECH

The 16-port RFID module SIM7400 is based on the next-generation Impinj E710 RAIN RFID reader chip. The SIM7400 module can be used for multiple antenna time-sharing applications; when the 8dBi antenna is used, the reading distance is more than 12 meters; the excellent multi-label anti-collision algorithm, the inventory is more than 900tags/s; the large-area aluminum alloy thermal conductive panel is used. Excellent heat dissipation.

SIM7300 | E710 | Buy UHF RFID Module Online | SILION TECH

The 8-port RFID module SIM7300 is based on the next-generation Impinj E710 RAIN RFID reader chip. The SIM7300 module can be used for multiple antenna time-sharing applications; when the 8dBi antenna is used, the reading distance is more than 12 meters; the excellent multi-label anti-collision algorithm, the inventory is more than 900tags/s; the large-area aluminum alloy thermal conductive panel is used. Excellent heat dissipation.

Technical Specifications

Hardware and OS
- API Support C, C#/.NET, Java

Physical Characteristics
- Dimensions 74.8mm × 48.5mm × 8mm
- Weight 58g

RFID Characteristics
- Air Protocols EPC Class 1 Gen 2 (ISO 18000-6C)
- Chipset Impinj E710
- Frequency USA: 902-928MHz FCC (NA, SA)
  EU: 865-868MHz (ETSI)
  CN: 920-925MHz (CMIIT)
- Programing Functions Tag RSSI Support
  Antenna Detector Support
  Temperature Detector Support
- RF Output Power *5dBm-30/33dBm (±1dBm) adjustable
- Work Mode Fixed / hop frequency optional
- Channel Isolation 32dB
- Sensitivity -86dBm

Connectivity
- Communications UART serial port (RS232),
  Baud rate 9600~921600bps
- General Purpose I/O 2 Inputs (DC 0~3.3V)
  2 Outputs (DC 0~3.3V)

Antenna
- Antenna Ports Four 50Ω SMA Connectors

Performance
- Reading Distance ≥22m with 8dBi antenna
- Anti-collision ≥1000 tags/s

Power
- Power Supply Input Voltage: 3.6V~5.0V +/-5%
  Power consumption in RF output mode: 7.5W, 1.6A@5V, 33dBm
  Power consumption in standby: 0.6W

Environmental
- Operating Temp -25°C to +65°C
- Storage Temp. -40°C - +85°C
- Humidity 5-95% non-condensing (+25°C)

How to use SIMX200(4-Port) Module Quick Start

Online Purchase

LCSC Electronics

https://www.lcsc.com/product-detail/RFID-Modules_SILION-SIM7200_C7383533.html
